TELINK BLE + IEEE802.15.4 MULTI STANDARD WIRELESS SOCS
03. September 2019 | Planegg
Telink's new generation TLSR8x5x family presents state of the art ultra low power (ULP) concurrent multi-protocol IoT solution at ISM 2.4GHz band.
It supports BLE 5.0 with 2X data rate, 4X long range (LR), 8X advertising packet extension (AE), up to 8 antennas for Indoor Positioning, both Telink proprietary and SIG BLE Mesh, Zigbee, RF4CE, HomeKit, Thread, ANT and 2.4GHz proprietary. It provides 32-bit MCU, BLE/802.15.4 2.4GHz Radio, 64KB SRAM, 512KB Flash, 14bit ADC with PGA, AMIC, DMIC, stereo audio output, 6-channel PWM, one quadrature decoder (QDEC), and flexible GPIO interfaces, and other peripheral blocks required for IoT applications.
The TLSR8x5x family also includes multi-stage power management design allowing ultra low power operation and making it the ideal candidate for wearable and power constraint applications. All optional features of BT 5.0, ZigBee 3.0 certification, Thread v1.1 and HomeKit authentication are already embedded with no additional external devices required.
The new 825x family is a world beater in the LP RF Connectivity.
Features:
Standards Supported
- BLE 5.0 (Long range, 2Mbps, AE), BT5.1 compatible (angled based positioning with up to 8x antennas)
- BLE Mesh, 6LoWPAN/Thread, 802.15.4 , Zigbee 3.0, RF4CE, HomeKit
- ANT/ANT+
Interfaces
- I/O: SPI, USB 2.0, I2C, UART, I2S
- Up to 32 GPIOs
- Voice In: Digital and Analog Mic, Dual-Mic
- Audio Out: SDM (Mono), Stereo
- PWM: Up to 6-channel
Performance
- RF Sensitivity
Up to -97dBm @ BLE 1Mbps;
Up to -100dBm @ 802.15.4
- Power @ 3V
TX whole chip 4.8mA @0dBm, 17mA@10dBm
RX whole chip 5.3mA
Sleep with SRAM: ~1uA
Sleep with external wakeup: 0.4uA
Max RF power: 10dBm
- 32bit MCU, up to 48MHz
512KB Flash with Flash encryption
64K SRAM (8K + 8K + 16K Retention)
Unique Chip ID
- BOM saving
32k crystal optional
Embedded RF match circuit
Minimal external components
- Power
Embedded LDO, DC-DC
ADC for battery monitoring
1.9 ~ 3.6V
- Sensor support
14bit ADC with PGA
Temperature sensor
IR modulators with FIFO control
Quadrature decoder
Low power comparator
SIM Card
- Native 7816 interface support
Package
Applications:
- QFN32, QFN48
- Smartphone and tablet accessories
- Wearable devices
- Building automation
- Consumer electronics
- RF remote control
- Wireless toys
- Smart grid
- Industrial control
- Sports and fitness tracking
- Smart lighting, smart home devices
- Intelligent logistics, transportation, city
- Health care
