Memory Modules

SMART’s DuraFlash™ R800v-S 2.5” SATA SSDs bring the advantages of non-volatile memory to embedded computing applications. The R800-S with SMART's proprietary SafeDATA™ power loss data protection technology are enterprise feature rich and reliable mass storage in a 2.5” form factor which is available in both commercial and industrial temperature ranges.

The R800v-S 2.5” SATA SSDs offer excellent sustained random read/write and sustained sequential read/write performance. The R800-S is suitable for applications that cannot tolerate variations in performance.

SMART’s DuraFlash™ R800v-S 2.5” SATA SSD family include:

• 240GB, 480GB, 960GB, 1920GB, 3840GB, 7680GB

SMART’s DuraFlash™ S1800v M.2 2280 PCIe NVMe products are robust SSDs with PCIe Gen 3x4 interface. These drives target server, storage cache/accelerators, networking, and data communications applications requiring reliable internal storage with a small footprint. They are also a natural fit for enterprise applications, including computing, medical, automotive, and industrial applications.

Utilizing PCIe Base 3.1 interface and compliant to NVMe v1.3 specification, S1800v M.2 2280 PCIe NVMe modules are easily integrated into a host system without any special BIOS modifications or additional device drivers. These products offer sustained read performance up to 3200 MB/s and burst write performance of up to 1000 MB/s.

The S1800v M.2 2280 PCIe NVMe products address the need for enhanced reliability by incorporating on-board error detection and correction, and static Wear-Leveling algorithms to provide reliable operation over the product life cycle..

SMART’s DuraFlash™ S1800v M.2 2280 PCIe NVMe SSD family include:

• 240GB, 480GB, 960GB, 1920GB

SMART’s DuraFlash™ N200v mSATA (MO-300A) SSDs provide an economic yet highly reliable mass storage in an mSATA form factor which is available in both commercial and industrial temperature ranges. The N200v product line is a SATA III solid state storage solution that offers excellent sequential read/write performance. It is suitable for embedded applications that require lower drive capacity and utilize the drive for boot up code and OS code storage.

SMART’s N200v mSATA (MO-300A) SSDs are offered with Triple-Level Cell (TLC) 3D NAND. They provide enhanced reliability by incorporating on-board error detection and correction, and static Wear-Leveling algorithms to provide reliable operation over the product life. SDRAM memory IC products include:

SMART’s DuraFlash™ N200v mSATA (MO-300A) SSD family include:

• 32GB, 64GB, 128GB, 256GB, 512GB, 1TB

SMART’s DuraFlash™ BGAE440 eMMC product family is an embedded memory solution that combines NAND Flash Memory, an embedded MMC (MultiMediaCard) controller, and advanced firmware in a small BGA (Ball Grid Array) package that provides a stable, yet cost effective high-density embedded storage. eMMC can simplify system design because of the widely adopted JEDEC® eMMC standard interface in host system chipsets and operating system software driver support.

DuraFlash BGAE440 eMMC is compliant to eMMC v5.1 specification and is available in the standard JEDEC 0.5mm pitch, 153-ball BGA package as well 1.0mm pitch, 100-ball BGA package. The 100-ball package offers larger ball pitch and ball diameter which enables lower cost PCB designs and simplifies PCB routing with wider metal traces. PSRAM memory IC products include:

SMART’s DuraFlash™ BGAE440 eMMC family include:

• 16GB, 32GB, 64GB, 128GB, 256GB

SMART’s DuraFlash™ RU150e Embedded USB (eUSB) Flash drive is designed as the main boot and storage device in embedded systems. The eUSB’s small form factor, lower power consumption, and fast access times, offer distinct technical advantages over more traditional mass storage devices.

Utilizing the USB interface, eUSB products are easily integrated into host systems without any special BIOS modifications or additional device drivers. SMART's RU150e eUSB products provide reliability by incorporating onboard error detection and correction. Static and dynamic Wear-Leveling algorithms also help to produce reliable operation over product life cycles. Serial NOR flash IC products include:

SMART’s DuraFlash™ RU150e Embedded USB (eUSB) Flash drive family include:

• 1GB, 2GB, 4GB, 8GB,16GB, 32GB

SMART’s DuraFlash™ RU350 USB Flash Drives are offered with Triple-Level Cell (TLC) 3D NAND flash in capacities of 16GB to 256GB. The USB Flash Drives complies with High-speed USB 3.0 interface & backward compatible with USB 2.0.

The RU350 USB Flash Drives feature compact small form factor in high capacity and provide enhanced reliability by incorporating onboard error detection and correction, and global Wear-Leveling algorithms that provide reliable operation over a product’s life.

SMART’s DuraFlash™ RU350 USB Flash Drive family include:

• 16GB, 32GB, 64GB, 128GB, 256GB

SMART’s DuraFlash™ RD230m microSD Cards & the RD230 SDXC Cards are fully SD UHS-I compliant. Both families are offered in commercial and industrial temperature versions in capacities from 16GB to 256GB. They are specifically designed to meet strict industrial operating and environmental requirements.

SMART’s DuraFlash™ R230m micro SD & RD230m SDXC CardU350 USB Flash Drive family include:

• 16GB, 32GB, 64GB, 128GB, 256GB

SMART’s DuraFlash™ XL CF Cards offer reliable, high performance in an industry standard CompactFlash® (CF) form factor. The industrial-grade XL CF Card products specifically support the OEM markets of networking, telecommunication and data communication, embedded computing, medical, and industrial applications.

Available in capacities from 128MB to 8GB, SMART’s XL CF Cards offers an advanced static Wear-Leveling algorithm for extending product lifespan in the most demanding OEM applications. Additionally, SMART has designed its product using Single-Level Cell (SLC). SLC NAND Flash technology is used for the enhanced data integrity and life time expectation in critical embedded applications.

SMART’s DuraFlash™ XL CF Card family include:

• 128MB, 256MB, 512MB,1GB, 2GB, 4GB, 8GB

SMART's DuraMemory™ NVDIMM combines nonvolatile memory with DRAM memory. NVDIMMs are used for logging and caching functions to accelerate system performance in server and storage applications. SMART’s DDR4 NVDIMM feature SafeStor™ technology which initiates backup and restore operations upon command from the host controller. NVDIMMs support multiple command delivery options to trigger a backup during a host detected power outage and recovery events.

DDR4 NVDIMM (Density) family include:

• 16GB, 32GB

SMART's DuraMemory™ SODIMM, or small outline dual in-line memory modules provide a smaller alternative than standard DIMM, roughly half the size of regular DIMM module. SODIMMs are used in systems with limited space, such as industrial control, embedded and rugged computing applications, and networking hardware, such as routers. SODIMMs are commonly used in harsh operating environments.

DDR4 SODIMM ECC (Density) family include:

• 4GB, 8GB, 16GB, 32GB

SMART's DuraMemory™ MIP, Module-in-a-Package™, is a tiny form factor memory module that combines the benefits of industry standard SODIMMs with the SMART proprietary stacking technology. About the size of a nickel, MIP occupies one-fifth the area of a SODIMM while offering higher performance with lower power. These benefits are critical for applications, such as broadcast video, mobile routing, high-end video and graphics cards and embedded computing applications where memory density in a small space is essential. MIPs contain on-package address and control signal termination, eliminating the need in DRAM-down board usage scenarios.

DDR4 MIP (Density) family include:

• 2GB,4GB, 8GB, 16GB

SMART's DuraMemory™ ULP UDIMMs (Ultra Low Profile) are used in space-constrained telecom, networking, and computing 'blade' applications, which have one or two DIMM sockets per CPU. Blade systems have a 1U height or less. ULP UDIMMs can be used vertically in these applications to maximize system density. ULP UDIMM ECC modules have error correction code built in, which detects and corrects common kinds of internal data corruption.

DDR4 UDIMM ECC (Density) family include:

• 4GB, 8GB, 16GB

DDR4 ULP UDIMM ECC (Density) family include:

• 16GB,32GB

SMART's DuraMemory™ RDIMMs use a hardware register that buffers the control signals to the modules. RDIMMs handle heavier electrical loads placed on high-speed, high-density memory modules better than the unbuffered DIMMs. When three or more DIMMs are used per memory channel, RDIMMs typically provide greater performance. SMART offers a wide variety of configurations, densities, and speeds to support diverse application requirements. (Enterprise grade option)

DDR4 (VLP) RDIMM (Density) family include:

• 4GB, 8GB, 16GB, 32GB, 64GB

DDR4 (VLP) Mini RDIMM (Density) family include:

• 4GB, 8GB, 16GB, 32GB
