NEW ATLANTIK ELEKTRONIK IOT DEVELOPMENT KIT
26. February 2018 | Planegg
Based on the most successful i.MX6 and i.MX6UL Single Board Computers from Digi, our kits provide out-of-the-box touch display and LTE / Wi-Fi / BT connectivity support for fastest prototyping and series production.
Solutions
Features/Benefits:
- Atlantik Services: support and consultancy throughout the entire product life cycle
- Plug & Play connectivity: LTE / GPS / Wi-Fi / BT / Ethernet
- Additional RF possibilities: 802.15.4., ZigBee, DigiMesh, NB-IoT, LTE-M, etc.
- Industrial interfaces: CAN / UART / SPI / ADC / I2C / GPIO / NFC and many more
- Customized display solutions
- TrustFence™ Linux Device Security Framework
All components can be adapted to your requirements in shortest time.
Kit Variants
IoT Development Kit I - ATXX-DK-1802001
- Digi ConnectCore6UL SBC Pro
- NXP i.MX6UL-2, Cortex-A7 @ 528 MHz
- 4GB eMMc + 256MB NAND, 256MB RAM
- 802.11a/b/g/n/ac + Bluetooth 4.2, 2x Fast Ethernet
IoT Development Kit II - ATXX-DK-1802002
- Digi ConnectCore6 SBC
- NXP i.MX6Quad (Cortex- A9) @1.2GHz
- 4 GB eMMC, 1GB DDR (64-bit)
- 802.11 a/b/g/n + Bluetooth 4.0, Gigabit Ethernet
Additional components in both kits:
- ATXX 7” 1024xRGB(3)x600 display
- Quectel EC25 PCIe LTE module
- Antenova antennas
- Accessories
