ENTRY LEVEL SOLUTIONS

Solutions

They offer reasonable video performance for display applications and multiple communication interfaces to bring comprehensive solutions to the market.

Products

Quectel SC20

SC20 is Quectel’s new generation of multi-mode Smart LTE Cat 4 module with built-in Android OS. It contains LTE and Wi-Fi & BT only versions. SC20 delivers maximally 150Mbps downlink and 50Mbps uplink data rates based on LTE network, and additionally supports wireless communication via IEEE 802.11 a/b/g/n (IEEE 802.11 b/g/n for SC20-CE/SC20-W by default) and BT4.1 LE (BT4.2 on Android 7.1 or later versions). It is ideal for both industrial and consumer applications requiring high data rate and high-speed internet access. SC20 is backward-compatible with existing EDGE and GSM/GPRS networks, ensuring that it can be connected even in remote areas devoid of 3G or LTE coverage.

MSM8909 Quad-Core ARM Cortex-A7 running up to 1.1 GHz
1/2 GB LPDDR3, 8/16GB eMMC
Cat 4 LTE
802.11a/b/g/n + BT 4.2

Thundercomm TurboX™ SDW2500 SoM

Thundercomm TurboX™ SDW2500 SOM is designed for wearable devices , powered by ARM Cortex-A7 microprocessor quad cores up to 1.094 GHz, targeted to deliver a robust foundation with extended battery life, an integrated sensor hub with pre-optimized algorithms, low power location tracking, and the fifth generation 4G LTE modem.

SDW2500 ARM Cortex-A7 Quad-Core @ 1.2GHz
eMCP: DDR3 4Gb + eMMC 4GB
802.11 b/g/n ,BT4 LE
GSM/CDMA/WCDMA/TD-SCDMA/LTE
Android 8.1

Inforce 6309™ Micro Single Board Computer (SBC)

The credit-card sized plug-and-play Inforce 6309 Micro SBC development kit provides industrial IoE system designers instant access to the compute power, comprehensive I/O, and connectivity of the Snapdragon 410E SoC. Powered by quad-core ARM®v8 Cortex®-A53 CPUs, the Inforce 6309 Micro SBC is the 3rd in the family of Snapdragon processor-based embedded computing platforms from Inforce. Unique features include support for WiFi/BLE, GPS, HDMI displays, dual-MIPI-CSI cameras, GbE ports, LVDS, and optional PoE and RS485 interfaces. With robust support for an upstream Linux kernel (Linaro) and Android (Lollipop), coupled with extended operating temperature and long lifecycle, the Inforce 6309 Micro SBC provides an ideal choice for a multitude of industrial applications.
